Kramer Protocol 3000
61
11.4 Parameters
11.4.1 Parity Types
Number
Value
0
No
1
Odd
2
Even
3
Mark
4
Space
11.4.2 Serial Types
Number
Value
0
232
1
485
11.4.3 IR Transmit Status
Number
Value
0
IR_SENT
1
IR_STOP
2
IR_BUSY
3
IR_WRONG_PARAM
4
IR-NOTHING_TO_STOP
11.4.4 IR Status
Number
Value
0
Sent
1
Stop
2
Done
3
Busy
4
Wrong Parameter
5
Nothing to Stop
6
Start
7
Timeout
8
Error
