40
Kramer Protocol 3000
11.3 Kramer Protocol 3000 – Detailed Commands
This section lists the detailed commands applicable to the FC-26.
Command - #
Command Type - System-mandatory
Command Name
Permission
Transparency
Set:
#
End User
Public
Get:
-
-
-
Description
Syntax
Set:
Protocol handshaking
#␍
Get:
-
-
Response
~nn@␠OK␍␊
Parameters
Response triggers
Notes
Use to validate the Protocol 3000 connection and get the machine number
Command - BUILD-DATE?
Command Type - System-mandatory
Command Name
Permission
Transparency
Set:
-
-
-
Get:
BUILD-DATE?
End User
Public
Description
Syntax
Set:
Read device build date
#BUILD-DATE␍
Get:
-
-
Response
~nn@BUILD-DATE␠date␠ time␍␊
Parameters
date - Format: YYYY/MM/DD where YYYY = Year, MM = Month, DD = Day
time - Format: hh:mm:ss where hh = hours, mm = minutes, ss = seconds
Response triggers
Notes
