Kramer Protocol 3000
39
11.2 Kramer Protocol 3000 – Command List
Command
Description
#
Protocol handshaking
BUILD-DATE?
Read device build date
DEL
Deletes a file
DIR
List files
ETH-PORT
Sets protocol port
FACTORY
Restart the machine with the default
FORMAT
Format the file system
FS-FREE?
Print free file space
GET
Get file content
HELP
List of commands
IR-LEARN
Send IR learning command
IR-SND
Send IR command to port
IR-STOP
Stop IR command to port
LOGIN
Set/get protocol permission
LOGOUT
Demotes the terminal security level to minimum
LOG_LEVEL?
Gets current logging level
MACH-NUM
Set device ID
MODEL?
Read device model
NAME
Set/get device (DNS) name
NAME-RST
Reset device name to default
NET-DHCP
Set/get DHCP mode
NET-GATE
Set/get gateway IP
NET-IP
Set/get device IP address
NET-MAC?
Get the MAC address
NET-MASK
Set/get the device subnet mask
PASS
Set/get the password for login level
PROT-VER?
Get protocol version
RESET
Reset device
SECUR
Set/get current security state
SN?
Get device serial number
TIME
Set/get the time
TIME-LOC
Set/get local time offset from UTC/GMT
TIME-SRV
Set/get time synchronization from server
UART
Set/get a port serial parameters
VERSION?
Get firmware version number
