34
Technical Specifications
OPTIONS:
19“ Rack adapter RK-3T
IR Cables—C-A35M/2IRE-10, C-A35M/IRR-3,
C-AS35M/AS35F-50, CA35M/IRE-10
Bulk cable for serial control—BC-1T-300M
Specifications are subject to change without notice at http://www.kramerelectronics.com
9.1 Data Handling Performance
The FC-26 is designed to support mainly AV-relevant RS-232 communication.
These devices have overall data bandwidth limits which should be high enough in
most AV installations to support the required communication bandwidth.
In extremely demanding cases, we recommend that you take into account the
bandwidth limitations.
The total sustained data bandwidth that each device can handle for all ports
simultaneously is 150kbps.
9.2 Example Bandwidth Calculation
The FC-26 has two serial ports. Each serial port can support up to:
150kbps / 2 = 75kbps
If each protocol commands is 100 bytes, (that is, 800 bits), you can safely send
and receive a minimum of 96 commands per second on each serial port. This is
shown using the following calculation:
(150kbps * 1024) / 800 bits / 2 = 96
The same calculation applies to all devices. A similar calculation applies when
fewer ports are used at the same time where a higher bandwidth per port can be
achieved.
In critical applications requiring a lossless data transfer, we recommend that
communication on all the other ports is stopped when making a long file transfer
(for example, when performing a firmware upgrade via one of the serial ports).
