36
Kramer Protocol 3000
11 Kramer Protocol 3000
The FC-26 can be operated using serial commands from a PC, remote controller
or touch screen using the Kramer Protocol 3000.
This section describes:
Kramer Protocol 3000 syntax (see Section 11.1)
Kramer Protocol 3000 commands (see Section 11.2)
11.1 Kramer Protocol 3000 – Syntax
11.1.1 Host Message Format
Start
Address
(optional)
Body
Delimiter
#
Destination_id@
Message
CR
11.1.1.1 Simple Command
Command string with only one command without addressing:
Start
Body
Delimiter
#
Command SP Parameter_1,Parameter_2,…
CR
11.1.1.2 Command String
Formal syntax with commands concatenation and addressing:
Start
Address
Body
Delimiter
#
Destination_id@
Command_1
Parameter1_1,Parameter1_2,…|
Command_2
Parameter2_1,Parameter2_2,…|
Command_3
Parameter3_1,Parameter3_2,…|…
CR
11.1.2 Device Message Format
Start
Address
(optional)
Body
delimiter
~
Sender_id@
Message
CR LF
11.1.2.1 Device Long Response
Echoing command:
Start
Address
(optional)
Body
Delimiter
~
Sender_id@
Command SP [Param1 ,Param2 …] result
CR LF
