Kramer Protocol 3000
41
Command - DEL
Command Type - File System
Command Name
Permission
Transparency
Set:
DEL
Administrator
Public
Get:
-
-
-
Description
Syntax
Set:
Delete file
#DEL␠ file_name␍
Get:
Response
~nn@DEL␠file_name␠OK ␍␊
Parameters
file_name - name of file to delete (file names are case-sensitive)
Response Triggers
Notes
Command - DIR
Command Type - File System
Command Name
Permission
Transparency
Set:
DIR
Administrator
Public
Get:
-
-
-
Description
Syntax
Set:
List files in device
#DIR␍
Get:
-
-
Response
Multi Line:
~nn@DIR␍␊
file_name TAB file_size␠bytes,␠ ID:␠file_id␍␊
TABfree_size␠ bytes.␍␊
Parameters
file_name - name of file
file_size - file size in bytes. A file can take more space on device memory
file_id - internal ID for file in file system
free_size - free space in bytes in device file system
Response Triggers
Notes
