Appendix

- 118 -

6-2-3 ConguringS/PDIFOut

The S/PDIF Out jack can transmit audio signals to an external decoder for decoding to get the best audio

quality.

1. Connecting a S/PDIF Out Cable:

Connect a S/PDIF optical cable to an external decoder for transmitting the S/PDIF digital audio signals.

2.ConguringS/PDIFOut:

Step 1:

While in the operating system, right-click on the icon

inthenoticationareaandselectPlayback devices.

Step 2:

On the Playback tab, right-click on SPDIF Out, select

Set as Default Device, and then open the Properties

dialog box.

Step 3:

You can go to the Supported Formats tab to select the

formats to be decoded or the Advanced tab to select the

sample rate and bit depth.

Connects to a S/PDIF optical cable
