- 32 -
Hardware Installation
6) CPU_OPT (Water Cooling CPU Fan Header)
The fan header is 4-pin and possesses a foolproof insertion design. When connecting a fan cable, be sure
to connect it in the correct orientation (the black connector wire is the ground wire). The speed control
function requires the use of a fan with fan speed control design.
Pin No. Denition
1 GND
2 Speed Control
3 Sense
4 VCC
7) LED_IO (I/O Shield Audio LED Power Connector)
The power connector provides power to the LEDs on the I/O shield on the motherboard back panel.
1
F_USB30
F_U
B_
F_ F_
_
B
BS_
B
SB_
B
_S
S_
_
B
_U
_
B
S
123
123
123
123
1
1
1
1
BSS
S
_S
SSU
1 2 3 4 5
S3
BSSS
U
__ 3
F_USB3F
S _
S _
S _
SF
B_
F
_0
S
S
_0F
_F
_
_
__B
Pin No. Denition
1 +5V
2 Red
3 Green
4 Blue
Step 1:
Install the included I/O shield into the chassis.
(For actual installation, please refer to the user
guide for your chassis.)
Step 2:
Place the motherboard into the chassis, aligning
the back panel connectors with the installed
I/O shield. Connect the power cable from the
I/O shield to the LED_IO connector on the
motherboard.
For how to turn on/off the I/O shield LED indicators, refer to the instructions on in Chapter 2, "BIOS
Setup," "Peripherals," or Chapter 5, "Unique Features," "APP Center\Ambient LED."
DEBUG
PORT
G.QBOFM
1
