- 29 -
Hardware Installation
1-13 Internal Connectors
Read the following guidelines before connecting external devices:
• First make sure your devices are compliant with the connectors you wish to connect.
• Before installing the devices, be sure to turn off the devices and your computer. Unplug the power
cord from the power outlet to prevent damage to the devices.
• After installing the device and before turning on the computer, make sure the device cable has
been securely attached to the connector on the motherboard.
2
5
8
11
19
1614
9
10
3
157
15
1) ATX_12V_2X4
2) ATX
3) ATX4P
4) CPU_FAN
5) SYS_FAN1/2/3/4/5
6) CPU_OPT
7) LED_IO
8) SATA EXPRESS
9) SATA3 0/1/2/3/4/5
10) SATA3 6/7
11) GSATA3 8/9
12) M2B_32G/M2C_32G
13) F_PANEL
14) F_AUDIO
15) F_USB30_1/F_USB30_2
16) F_USB1/F_USB2
17) TPM
18) BAT
19) CLR_CMOS
46
18 51317
9
5
5
12
12
8
