Unique Features

5-1-3 Using Q-Flash Plus

A. Before You Begin

1. FromGIGABYTE'swebsite,downloadthelatestcompressedBIOSupdatelethatmatchesyourmotherboard

model.

2. UncompressthedownloadedBIOSle,saveittoyourUSBashdrive,andrenameittoGIGABYTE.bin.

Note:TheUSBashdrivemustusetheFAT32/16lesystemanditmustbeaUSB2.0ashdrive.

3. InserttheUSBashdriveintothewhiteUSBportonthebackpanel.

B. Using Q-Flash Plus

If both the main and backup BIOS fail during system boot, wait for 15-20 seconds, the system will automatically

searchandmatchtheBIOSleintheUSBashdriveonthewhiteUSBport.TheFBIOS_LEDwillashwhen

theBIOSmatchingandashingactivitiesstart.

Waitfor2-3minutesandtheFBIOS_LEDwillstopashingwhenthemainBIOSashingiscomplete.

AfterthemainBIOSisashed,thesystemwillrebootautomatically and then DualBIOS

™

will

continue to update the backup BIOS. After completion, the system will reboot again and boot from

the main BIOS for normal operation.
