Gigabyte ga-z170x-gaming g1 [71/136] C 1 uefiraidconfiguration

- 71 -

Conguring a RAID Set

C-1.UEFIRAIDConguration

OnlyWindows10/8.164-bitsupportsUEFIRAIDconguration.

Step 1:

In BIOS Setup, go to BIOS Features and set Windows 8/10 Features to Windows 8/10 and CSM Support to

Disabled (Figure 2). Save the changes and exit BIOS Setup.

Step 2:

After the system reboot, enter BIOS Setup again. Then enter the Peripherals\Intel(R) Rapid Storage Technology

sub-menu (Figure 3).

Figure 2

Figure 3
