Gigabyte ga-z170x-gaming g1 [26/136] 10 installing the gc m2 u2 minisas

- 26 -

Hardware Installation

1-10 Installing the GC-M2-U2-MiniSAS

Step 1:

Use a screw driver to unfasten the screw and nut from the motherboard.

Locate the proper mounting hole for the GC-M2-U2-MiniSAS and screw

thenutrst.Thenslideitintotheconnectoratanangle.

Step 3:

Remove the protective cover from the SAS connector on the GC-M2-

U2-MiniSAS and connect one end of the SSD cable to the connector.

Step 2:

Press the GC-M2-U2-MiniSAS down and then secure it with the screw.

Step 4:

Connect the other end of the cable to the SSD to complete.
