BIOS Setup

- 61 -

& Storage Boot Option Control

Allows you to select whether to enable the UEFI or legacy option ROM for the storage device controller.

Disabled Disables option ROM.

Legacy Only Enables legacy option ROM only. (Default)

UEFI Only Enables UEFI option ROM only.

 ThisitemiscongurableonlywhenCSM Support is set to Enabled.

& Other PCI Device ROM Priority

Allows you to select whether to enable the UEFI or Legacy option ROM for the PCI device controller other

than the LAN, storage device, and graphics controllers.

Disabled Disables option ROM.

Legacy Only Enables legacy option ROM only.

UEFI Only Enables UEFI option ROM only. (Default)

 ThisitemiscongurableonlywhenCSM Support is set to Enabled.

& Network Stack

Disables or enables booting from the network to install a GPT format OS, such as installing the OS from

the Windows Deployment Services server. (Default: Disabled)

& Ipv4 PXE Support

 EnablesordisablesIPv4PXESupport.ThisitemiscongurableonlywhenNetwork Stack is enabled.

& Ipv6 PXE Support

 EnablesordisablesIPv6PXESupport.ThisitemiscongurableonlywhenNetwork Stack is enabled.

& Administrator Password

 Allowsyoutocongureanadministratorpassword.Press<Enter>onthisitem,typethepassword,and

thenpress<Enter>.Youwillberequestedtoconrmthepassword.Typethepasswordagainandpress

<Enter>. You must enter the administrator password (or user password) at system startup and when entering

BIOS Setup. Differing from the user password, the administrator password allows you to make changes to

all BIOS settings.

& User Password

 Allowsyoutocongureauserpassword.Press<Enter>onthisitem,typethepassword,andthenpress

<Enter>.Youwillberequestedtoconrmthepassword.Typethepasswordagainandpress<Enter>.

You must enter the administrator password (or user password) at system startup and when entering BIOS

Setup. However, the user password only allows you to make changes to certain BIOS settings but not all.

To cancel the password, press <Enter> on the password item and when requested for the password, enter

thecorrectonerst.Whenpromptedforanewpassword,press<Enter>withoutenteringanypassword.

Press<Enter>againwhenpromptedtoconrm.

 NOTE:BeforesettingtheUserPassword,besuretosettheAdministratorPasswordrst.
