![Zyxel MGS-3712F [101/284] Command summary](/views2/1169509/page101/bg65.png)
Ethernet Switch CLI Reference Guide
101
CHAPTER 23
IGMP Snooping Commands
Use these commands to configure IGMP snooping on the Switch.
23.1 Command Summary
The following section lists the commands for this feature.
Table 62 igmp-flush Command Summary
COMMAND DESCRIPTION M P
igmp-flush Removes all multicast group information. E 13
Table 63 igmp-snooping Command Summary
COMMAND DESCRIPTION M P
show igmp-snooping Displays global IGMP snooping settings. E 3
show multicast [vlan] Displays multicast status, including the port number, VLAN ID
and multicast group members on the Switch. Optionally,
displays the type of each multicast VLAN.
E3
igmp-snooping Enables IGMP snooping. C 13
no igmp-snooping Disables IGMP snooping. C 13
igmp-snooping filtering Enables IGMP filtering on the Switch. Ports can only join
multicast groups specified in their IGMP filtering profile.
C13
igmp-snooping filtering profile
<name> start-address <ip> end-
address <ip>
Sets the range of multicast address(es) in a profile.
name: 1-32 alphanumeric characters
C13
no igmp-snooping filtering Disables IGMP filtering on the Switch. C 13
no igmp-snooping filtering
profile <name>
Removes the specified IGMP filtering profile. You cannot
delete an IGMP filtering profile that is assigned to any ports.
C13
no igmp-snooping filtering
profile <name> start-address
<ip> end-address <ip>
Clears the specified rule of the specified IGMP filtering profile. C 13
igmp-snooping 8021p-priority <0-
7>
Sets the 802.1p priority for outgoing igmp snooping packets. C 13
no igmp-snooping 8021p-priority Disables changing the priority of outgoing IGMP control
packets.
C13
igmp-snooping host-timeout <1-
16711450>
Sets the host timeout value. C 13
igmp-snooping leave-timeout <1-
16711450>
Sets the leave timeout value C 13
