Chapter 2 Privilege Level and Command Mode
Ethernet Switch CLI Reference Guide
20
Each command is usually in one and only one mode. If a user wants to run a particular
command, the user has to change to the appropriate mode. The command modes are organized
like a tree, and users start in enable mode. The following table explains how to change from
one mode to another.
2.3 Listing Available Commands
Use the help command to view the executable commands on the Switch. You must have the
highest privilege level in order to view all the commands. Follow these steps to create a list of
supported commands:
1 Log into the CLI. This takes you to the enable mode.
config-rip sysname(config-rip)# Configure Routing Information Protocol (RIP).
config-vrrp sysname(config-vrrp)# Configure Virtual Router Redundancy Protocol (VRRP).
Table 7 Command Modes for Privilege Levels 13-14 and the Types of Commands in Each One
MODE PROMPT COMMAND FUNCTIONS IN THIS MODE
Table 8 Changing Between Command Modes for Privilege Levels 13-14
MODE ENTER MODE LEAVE MODE
enable -- --
config configure exit
config-interface interface port-channel <port-list> exit
config-mvr mvr <1-4094> exit
config-vlan vlan <1-4094> exit
config-route-domain interface route domain <ip-address>/<mask-bits> exit
config-dvmrp router dvmrp exit
config-igmp router igmp exit
config-ospf router ospf <router-id> exit
config-rip router rip exit
config-vrrp router vrrp network <ip-address>/<mask-bits>
vr-id <1~7> uplink-gateway <ip-address>
exit
