Ethernet Switch CLI Reference Guide
97
CHAPTER 21
IEEE 802.1x Authentication
Commands
Use these commands to configure IEEE 802.1x authentication.
" Do not forget to configure the authentication server.
21.1 Command Summary
The following section lists the commands for this feature.
21.2 Command Examples
This example configures the Switch in the following ways:
Table 59 port-access-authenticator Command Summary
COMMAND DESCRIPTION M P
show port-access-authenticator Displays all port authentication settings. E 3
show port-access-authenticator
<port-list>
Displays port authentication settings on the specified port(s). E 3
port-access-authenticator Enables 802.1x authentication on the Switch. C 13
no port-access-authenticator Disables port authentication on the Switch. C 13
port-access-authenticator
<port-list>
Enables 802.1x authentication on the specified port(s). C 13
no port-access-authenticator
<port-list>
Disables authentication on the listed ports. C 13
port-access-authenticator
<port-list> reauthenticate
Sets a subscriber to periodically re-enter his or her username
and password to stay connected to a specified port.
C13
no port-access-authenticator
<port-list> reauthenticate
Disables the re-authentication mechanism on the listed
port(s).
C13
port-access-authenticator
<port-list> reauth-period <1-
65535>
Specifies how often (in seconds) a client has to re-enter the
username and password to stay connected to the specified
port(s).
C13
