Chapter 9 CFM Commands
Ethernet Switch CLI Reference Guide
53
This example displays all neighbors’ MEP port information in the MIP-CCM databases.
The following table describes the labels in this screen.
This example assigns a virtual MAC address to port 3 and displays the MAC addresses of the
ports 2 ~ 4. The assigned virtual MAC address should be unique in both the Switch and the
network to which it belongs.
sysname# show ethernet cfm local stack mip mip-ccmdb
MIP CCM DB
Port VID Source Address Retained
---- ---- ----------------- ---------
2 1 00:19:cb:00:00:04 0 hr(s)
7 1 00:19:cb:00:00:06 0 hr(s)
sysname#
Table 29 show cfm-action mipccmdb
LABEL DESCRIPTION
Port Displays the number of the port on which this CCM was received.
VID Displays the MA VLAN ID of the last received CCM.
Source Address Displays the MAC address of the remote MEP.
Retained Displays how long an entry has been kept in the database.
sysname# config
sysname(config)# interface port-channel 3
sysname(config-interface)# ethernet cfm virtual-mac 00:19:cb:12:34:56
sysname(config-interface)# exit
sysname(config)# exit
sysname# show ethernet cfm virtual-mac port 2-4
Virtual MACPort MAC
---- -----------------
2 00:19:cb:00:00:02
3 00:19:cb:12:34:56
4 00:19:cb:00:00:02
sysname#
