Zyxel MGS-3712F [244/284] Chapter 73 additional commands
![Zyxel MGS-3712F [244/284] Chapter 73 additional commands](/views2/1169509/page244/bgf4.png)
Chapter 73 Additional Commands
Ethernet Switch CLI Reference Guide
244
boot image <1|2> The Switch supports dual firmware images, ras-0 and ras-1.
Run this command, where <index> is 1 (ras-0) or 2 (ras-1) to
specify which image is updated when firmware is loaded
using the web configurator and to specify which image is
loaded when the Switch starts up.
E13
cable-diagnostics <port-list> Perform a physical wire-pair test of the Ethernet connections
on the specified port(s).
Ok: The physical connection between the wire-pair is okay.
Open: There is no physical connection between the wire-pair.
E13
ping <ip|host-name> [vlan <vlan-
id>] [size <0-1472>] [-t]
Sends Ping packets to the specified Ethernet device.
vlan-id: Specifies the VLAN ID to which the Ethernet
device belongs.
size <0-1472>: Specifies the size of the Ping packet.
-t: Sends Ping packets to the Ethernet device indefinitely.
Press [CTRL]+C to terminate the Ping process.
E0
ping help Provides more information about the specified command. E 0
reload config [1|2] Restarts the system (warm reboot) with the specified
configuration file.
1: config-1
2: config-2
E13
show alarm-status Displays alarm status. E 0
show cpu-utilization Displays the CPU utilization statistics on the Switch. E 0
show hardware-monitor <C|F> This command is not available in all models.
Displays current hardware monitor information with the
specified temperature unit (Celsius C or Fahrenheit F).
E0
show poe-status This command is available for PoE models only.
Displays information about Power over Ethernet (PoE).
E0
show sfp <port-list> Displays real-time SFP (Small Form Facter Pluggable)
transceiver operating parameters on specified SFP port(s).
The parameters include, for example, module temperature,
module voltage, transmitting and receiving power.
E3
show interfaces transceiver
<port-list>
Displays real-time SFP (Small Form Facter Pluggable)
transceiver information and operating parameters on
specified SFP port(s). The parameters include, for example,
module temperature, module voltage, transmitting and
receiving power.
E3
show system-information Displays general system information. E 0
show version [flash] Display the version of the currently running firmware on the
Switch. Optionally, display the version of the currently
installed firmware on the flash memory.
E0
test interface port-channel
<port-list>
Performs an internal loopback test on the specified ports. The
test returns Passed! or Failed!.
E13
traceroute <ip|host-name> [vlan
<vlan-id>] [ttl <1-255>] [wait
<1-60>] [queries <1-10>]
Determines the path a packet takes to the specified Ethernet
device.
vlan <vlan-id>: Specifies the VLAN ID to which the
Ethernet device belongs.
ttl <1-255>: Specifies the Time To Live (TTL) period.
wait <1-60>: Specifies the time period to wait.
queries <1-10>: Specifies how many times the Switch
performs the traceroute function.
E0
Table 152 Command Summary: Additional Enable Mode (continued)
COMMAND DESCRIPTION M P
