Chapter 9 CFM Commands
Ethernet Switch CLI Reference Guide
51
9.4 Command Examples
This example creates MD1 (with MD index 1 and level 1) and MA2 (with MA index 2 and
VLAN ID 2) under MD1 that defines a CFM domain.
" Remember to save new settings using the write memory command.
This example deletes MA2 (with MA index 2) from MD1 (with MD index 1).
show ethernet cfm local stack mep Displays a list of the MEP(s). E 13
show ethernet cfm local stack mep
<mep-id> ma <ma-index> md <md-
index>
Displays the specified MEP’s general, fault notification
generator, continuity-check, loopback and link trace
information.
E13
show ethernet cfm local stack mep
<mep-id> ma <ma-index> md <md-
index> mep-ccmdb [remote-mep <mep-
id>]
Displays the specified MEP’s MEP-CCM database
information. Each MEP maintains an MEP CCM
database which stores information about remote MEPs in
the MA when receiving CCMs.
E13
show ethernet cfm local stack mip Displays a list of the MIP(s). E 13
show ethernet cfm local stack mip
mip-ccmdb
Displays the MIP-CCM database. E 13
show ethernet cfm remote Displays a list of MA(s), MEP(s) and the remote MEP(s)
under the configured MD(s).
E13
show ethernet cfm virtual-mac Displays all virtual MAC addresses. E 13
show ethernet cfm virtual-mac port
<port-list>
Displays the MAC address(es) of the specified port(s). E 13
Table 28 CFM Command Summary (continued)
COMMAND DESCRIPTION M P
sysname# config
sysname(config)# ethernet cfm md 1 format string name MD1 level 1
sysname(config)# ethernet cfm ma 2 format string name MA2 md 1 primary-
vlan 2
sysname(config-ma)# exit
sysname(config)# exit
sysname# write memory
sysname# config
sysname(config)# no ethernet cfm ma 2 md 1
sysname(config)# exit
sysname# write mem
