Chapter 73 Additional Commands
Ethernet Switch CLI Reference Guide
250
The following table describes the labels in this screen.
This example displays run-time SFP (Small Form Facter Pluggable) parameters on ports 9 (the
first SFP port 0, with an SFP transceiver installed) and 10 (the second SFP port 1, no SFP
transceiver installed) on the
Switch. You can also see the alarm and warning threasholds for
temperature, voltage, transmission bias, transmission and receiving power as shown.
This example runs an internal loopback test on ports 3-6.
Table 160 show system-information
LABEL DESCRIPTION
System Name This field displays the system name (or hostname) of the Switch.
System Contact This field displays the name of the person in charge of this Switch. Use the
snmp-server command to configure this. See Chapter 55 on page 189.
System Location This field displays the geographic location of this Switch. Use the snmp-
server command to configure this. See Chapter 55 on page 189.
Ethernet Address This field displays the MAC address of the Switch.
ZyNOS F/W Version This field displays the firmware version the Switch is running.
RomRasSize This field displays how much ROM is used.
System up Time This field displays how long the switch has been running since it last started
up.
Bootbase Version This field displays the bootbase version the Switch is using.
ZyNOS CODE This field displays the ZyNOS operating system version the Switch is using.
Product Model This field displays the model name.
sysname# show sfp 9-10
SFP : 0
Part Number : SFP-SX-DDM
Series Number : S081113001132
Revision : V1.0
Transceiver : 1000BASE-SX
Temperature(C) Alarm(80.00 ~ 0.00), Warning(75.00 ~ 5.00), Current(38.00)
Voltage(V) Alarm(3.50 ~ 3.10), Warning(3.45 ~ 3.15), Current(3.37)
Tx Bias(mA) Alarm(100.05 ~ 1.00), Warning(90.04 ~ 2.00), Current(5.25)
Tx Power(dBm) Alarm(-2.99 ~ -8.98), Warning(-3.49 ~ -8.48), Current(-6.05)
Rx Power(dBm) Alarm(-2.99 ~ -18.01), Warning(-3.49 ~ -17.39), Current(-4.24)
SFP : 1
Not Available
sysname# test interface port-channel 3-6
Testing internal loopback on port 3 :Passed!
Ethernet Port 3 Test ok.
Testing internal loopback on port 4 :Passed!
Ethernet Port 4 Test ok.
Testing internal loopback on port 5 :Passed!
Ethernet Port 5 Test ok.
Testing internal loopback on port 6 :Passed!
Ethernet Port 6 Test ok.
