Ethernet Switch CLI Reference Guide
129
CHAPTER 31
Logging Commands
Use these commands to manage system logs.
31.1 Command Summary
The following section lists the commands for this feature.
31.2 Command Examples
This example displays the system logs.
Table 79 logging Command Summary
COMMAND DESCRIPTION M P
show logging Displays system logs. E 3
no logging Clears system logs. E 13
sysname# show logging
1 Thu Jan 1 00:02:08 1970 PP05 -WARN SNMP TRAP 3: link up
2 Thu Jan 1 00:03:14 1970 INFO adjtime task pause 1 day
3 Thu Jan 1 00:03:16 1970 PP0f -WARN SNMP TRAP 26: Event On Trap
4 Thu Jan 1 00:03:16 1970 PINI -WARN SNMP TRAP 1: warm start
5 Thu Jan 1 00:03:16 1970 PINI -WARN SNMP TRAP 3: link up
6 Thu Jan 1 00:03:16 1970 PINI INFO main: init completed
7 Thu Jan 1 00:00:13 1970 PP26 INFO adjtime task pause 1 day
8 Thu Jan 1 00:00:14 1970 PP0f -WARN SNMP TRAP 26: Event On Trap
9 Thu Jan 1 00:00:14 1970 PINI -WARN SNMP TRAP 0: cold start
10 Thu Jan 1 00:00:14 1970 PINI INFO main: init completed
11 Thu Jan 1 00:00:04 1970 PP05 -WARN SNMP TRAP 3: link up
11 Thu Jan 1 00:00:04 1970 PP05 -WARN SNMP TRAP 3: link up
Clear Error Log (y/n):
