Zyxel MGS-3712F [235/284] This example shows how to configure ports 1 and 2 on the switch to tag incoming frames with the service provider s vid of 37 ports are connected to customer a network this example also shows how to set the priority for ports 1 and 2 to 3
![Zyxel MGS-3712F [235/284] This example shows how to configure ports 1 and 2 on the switch to tag incoming frames with the service provider s vid of 37 ports are connected to customer a network this example also shows how to set the priority for ports 1 and 2 to 3](/views2/1169509/page235/bgeb.png)
Chapter 70 VLAN Stacking Commands
Ethernet Switch CLI Reference Guide
235
This example shows how to configure ports 1 and 2 on the Switch to tag incoming frames with
the service provider’s VID of 37 (ports are connected to customer A network). This example
also shows how to set the priority for ports 1 and 2 to 3.
sysname(config)# vlan-stacking
sysname(config)# interface port-channel 1-2
sysname(config-interface)# vlan-stacking role access
sysname(config-interface)# vlan-stacking spvid 37
sysname(config-interface)# vlan-stacking priority 3
sysname(config-interface)# exit
sysname(config)# exit
sysname# show vlan-stacking
Switch Vlan Stacking Configuration
Operation: active
STPID: 0x8100
Port Role SPVID Priority
01 access 37 3
02 access 37 3
03 access 1 0
04 access 1 0
05 access 1 0
....
