![Zyxel MGS-3712F [143/284] Mirror commands](/views2/1169509/page143/bg8f.png)
Ethernet Switch CLI Reference Guide
143
CHAPTER 38
Mirror Commands
Use these commands to copy a traffic flow for one or more ports to a monitor port (the port
you copy the traffic to) so that you can examine the traffic on the monitor port without
interference.
" Use the running configuration commands to look at the current mirror settings.
See Chapter 54 on page 187.
" mirror-filter commands are not supported on all Switch models.
38.1 Command Summary
The following section lists the commands for this feature.
Table 89 mirror Command Summary
COMMAND DESCRIPTION M P
mirror-port Enables port mirroring on the Switch. C 13
mirror-port <port-num> Specifies the monitor port (the port to which traffic flow is
copied) for port mirroring.
C13
no mirror-port Disables port mirroring on the Switch. C 13
interface port-channel <port-
list>
Enters config-interface mode for the specified port(s). C 13
mirror Enables port mirroring in the interface. C 13
mirror dir
<ingress|egress|both>
Enables port mirroring for incoming (ingress), outgoing
(egress) or both incoming and outgoing (both) traffic.
C13
no mirror Disables port mirroring on the port(s). C 13
