About This CLI Reference Guide
Ethernet Switch CLI Reference Guide
3
About This CLI Reference Guide
Intended Audience
This manual is intended for people who want to configure ZyXEL Switches via Command
Line Interface (CLI). You should have at least a basic knowledge of TCP/IP networking
concepts and topology.
The version number on the cover page refers to the latest firmware version supported by the
ZyXEL Switches. This guide applies to version 3.80 and 3.90 at the time of writing.
" This guide is intended as a command reference for a series of products.
Therefore many commands in this guide may not be available in your product.
See your User’s Guide for a list of supported features and details about feature
implementation.
Please refer to www.zyxel.com or your product’s CD for product specific User Guides and
product certifications.
How To Use This Guide
•Read the How to Access the CLI chapter for an overview of various ways you can get to
the command interface on your Switch.
• Use the Reference section in this guide for command syntax, description and examples.
Each chapter describes commands related to a feature.
• To find specific information in this guide, use the Contents Overview, the Index of
Commands, or search the PDF file. E-mail techwriters@zyxel.com.tw if you cannot find
the information you require.
CLI Reference Guide Feedback
Help us help you. Send all Reference Guide-related comments, questions or suggestions for
improvement to the following address, or use e-mail instead. Thank you!
The Technical Writing Team,
ZyXEL Communications Corp.,
6 Innovation Road II,
Science-Based Industrial Park,
Hsinchu, 300, Taiwan.
E-mail: techwriters@zyxel.com.tw
