Chapter 9 CFM Commands
Ethernet Switch CLI Reference Guide
48
9.2 User Input Values
This section lists the common term definition appears in this chapter. Refer to User’s Guide for
more detailed information about CFM.
9.3 Command Summary
The following section lists the commands for this feature.
Table 27 CFM command user input values
USER INPUT DESCRIPTION
mep-id This is the maintenance endpoint identifier (1~8191).
ma-index This is the maintenance association (MA) index number
(1~4294967295).
md-index This is the maintenance domain (MD) index number
(1~4294967295).
mac-address This is the remote maintenance endpoint’s MAC address or a
virtual MAC address assigned to a port.
A switch has one or two MAC addresses only. If you do not use
virtual MAC addresses with CFM, all CFM ports will use the
Switch’s MAC address and appear as one port. If you want
unique CFM ports, you need to assign virtual MAC addresses. If
you use virtual MAC addresses, make sure that all virtual MAC
addresses are unique in both the switch and the network to which
it belongs.
Table 28 CFM Command Summary
COMMAND DESCRIPTION M P
clear ethernet cfm linktrace Clears the link trace database. E 13
clear ethernet cfm mep-ccmdb Clears the MEP CCM database. E 13
clear ethernet cfm mip-ccmdb Clears the MIP CCM database. E 13
clear ethernet cfm mep-defects Clears the MEP-defects database. E 13
ethernet cfm Enables CFM on the Switch. C 13
ethernet cfm md <md-index> format
<dns|mac|string> name <md-name>
level <0-7>
Creates an MD (Maintenance Domain) with the specified
name and level number.
md-name: Enters a domain name, MAC address or a
descriptive name for the MD.
C13
ethernet cfm ma <ma-index> format
<vid|string|integer> name <ma-name>
md <md-index> primary-vlan <1-4094>
Creates an MA (Maintenance Association) and defines
its VLAN ID under the MD. You can also define the
format which the Switch uses to send this MA information
in the domain (MD).
ma-name: Enters a VLAN ID, a descriptive name or a 2-
octet integer for the MA.
Note: If you set the format to vid, the VLAN
ID should be the same as the VLAN ID
you use to identify the MA.
C13
cc-interval
<100ms|1s|10s|1min|10min>
Sets how often an MEP sends a connectivity check
message (CCM).
C13
