Ethernet Switch CLI Reference Guide
93
CHAPTER 20
HTTPS Server Commands
Use these commands to configure the HTTPS server on the Switch.
20.1 Command Summary
The following section lists the commands for this feature.
Table 56 https Command Summary
COMMAND DESCRIPTION M P
show https Displays the HTTPS settings, statistics, and sessions. E 3
show https certificate Displays the HTTPS certificates. E 3
show https key <rsa|dsa> Displays the HTTPS key. E 3
show https session Displays current HTTPS session(s). E 3
https cert-regeneration
<rsa|dsa>
Re-generates a certificate. C 13
