Chapter 9 CFM Commands
Ethernet Switch CLI Reference Guide
49
mhf-creation < none | default |
explicit>
Sets MHF (MIP Half Function).
Select none and no MIP can be created automatically for
this MA.
Select default to automatically create MIPs for this MA
and on the ports belonging to this MA’s VLAN when there
are no lower configured MD levels or there is an MEP at
the next lower configured MD level on the port.
Select explicit to automatically create MIPs for this
MA and on the ports belonging to this MA’s VLAN only
when there is an MEP at the next lower configured MD
level on the port.
C13
id-permission < none | chassis
| management | chassis-
management>
Sets what’s to be included in the sender ID TLV (Type-
Length-Value) transmitted by CFM packets.
Select none to not include the sender ID TLV.
Select chassis to include the chassis information.
Select management to include the management
information.
Select chassis-management to include both chassis
and management information.
C13
exit Exits from the config-ma mode. C 13
remote-mep <mep-id> Sets a remote MEP in an MA. C 13
mep <mep-id> interface port-
channel <port> direction
<up|down> priority <0-7>
Sets an MEP in an MA.
up|down: The traffic direction.
0-7: The priority value of the CCMs or LTMs transmitted
by the MEP. 1 is the lowest, then 2, 0 and 3 ~ 7.
C13
mep <mep-id> interface port-
channel <port> direction
<up|down> priority <0-7>
inactive
Disables a specified MEP. C 13
mep <mep-id> interface port-
channel <port> direction
<up|down> priority <0-7> cc-
enable
Enables Connectivity Check (CC) to allow an MEP
sending Connectivity Check Messages (CCMs)
periodically to other MEPs.
C13
no remote-mep <mep-id> Deletes a specified destination MEP. C 13
no mep <mep-id> Deletes a specified MEP. C 13
no mep <mep-id> inactive Enables an MEP. C 13
no mep <mep-id> cc-enable Disallows an MEP sending Connectivity Check
Messages (CCMs) periodically to other MEPs.
C13
ethernet cfm loopback remote-mep
<mep-id> mep <mep-id> ma <ma-index>
md <md-index> [size <0-1500>][count
<1-1024>]
Specifies the remote MEP ID, local MEP ID, MA index
and MD index to perform a loopback test.
This enables the MEP port (with the specified MEP ID) in
a specified CFM domain to send the LBMs (Loop Back
Messages) to a specified remote end point.
You can also define the packet size (from 0 to 1500
bytes) and how many times the Switch sends the LBMs.
E13
Table 28 CFM Command Summary (continued)
COMMAND DESCRIPTION M P
