Ethernet Switch CLI Reference Guide
233
CHAPTER 70
VLAN Stacking Commands
Use these commands to add an outer VLAN tag to the inner IEEE 802.1Q tagged frames that
enter your network.
70.1 Command Summary
The following section lists the commands for this feature.
Table 148 vlan-stacking Command Summary
COMMAND DESCRIPTION M P
show vlan-stacking Displays VLAN stacking settings. E 3
vlan-stacking Enables VLAN stacking on the Switch. C 13
no vlan-stacking Disables VLAN stacking on the Switch. C 13
no vlan-stacking selective-qinq
interface port-channel <port>
cvid <vlan-id>
Removes the specified selective VLAN stacking rule. C 13
no vlan-stacking selective-qinq
interface port-channel <port>
cvid <vlan-id> inactive
Enables the specified selective VLAN stacking rule. C 13
vlan-stacking selective-qinq
name <name> interface port-
channel <port> cvid <cvid> spvid
<spvid> priority <0-7>
Creates a selective VLAN stacking rule.
cvid: 1 - 4094. This is the VLAN tag carried in the packets
from the subscribers.
spvid: 1 - 4094: This is the service provider’s VLAN ID (the
outer VLAN tag).
C13
vlan-stacking selective-qinq
name <name> interface port-
channel <port> cvid <cvid> spvid
<spvid> priority <0-7> inactive
Disables the specified selective VLAN stacking rule. C 13
vlan-stacking <sptpid> Sets the SP TPID (Service Provider Tag Protocol Identifier).
SP TPID is a standard Ethernet type code identifying the
frame and indicating whether the frame carries IEEE 802.1Q
tag information. Enter a four-digit hexadecimal number from
0000 to FFFF.
C13
interface port-channel <port-
list>
Enters config-interface mode for the specified port(s). C 13
vlan-stacking priority <0-7> Sets the priority of the specified port(s) in port-based VLAN
stacking.
C13
