Chapter 50 Queuing Commands
Ethernet Switch CLI Reference Guide
179
50.3 Command Examples: Port by Port Configuration
This example configures WFQ on ports 1-5 and assigns weight values (1,2,3,4,12,13,14,15) to
the physical queues (Q0 to Q8).
50.4 Command Summary: System-Wide Configuration
The following section lists the commands for this feature.
ge-spq <q0|q1| ... |q7> Enables SPQ starting with the specified queue and
subsequent higher queues on the Gigabit ports.
C13
hybrid-spq lowest-queue
<q0|q1| ... |q7>
Enables SPQ starting with the specified queue and
subsequent higher queues on the ports.
C13
wrr Sets the switch to use Weighted Round Robin (WRR) on the
specified ports.
C13
wfq Sets the switch to use Weighted Fair Queuing (WFQ) on the
specified ports.
C13
weight <wt1> <wt2> ... <wt8> Assigns a weight value to each physical queue on the Switch.
When the Switch is using WRR or WFQ, bandwidth is divided
across different traffic queues according to their weights.
Queues with larger weights get more service than queues
with smaller weights. Weight values range: 1-15.
C13
Table 107 Queuing Command Summary (continued)
COMMAND DESCRIPTION M P
sysname(config)# interface port-channel 1-5
sysname(config-interface)# wfq
sysname(config-interface)# weight 1 2 3 4 12 13 14 15
Table 108 Queueing Command Summary
COMMAND DESCRIPTION M P
queue priority <0-7> level <0-7> Sets the IEEE 802.1p priority level-to-physical queue
mapping.
priority <0-7>: IEEE 802.1p defines up to eight separate
traffic types by inserting a tag into a MAC-layer frame that
contains bits to define class of service. Frames without an
explicit priority tag are given the default priority of the ingress
port.
level <0-7>: The Switch has up to 7 physical queues that
you can map to the 8 priority levels. On the Switch, traffic
assigned to higher index queues gets through faster while
traffic in lower index queues is dropped if the network is
congested.
Note: Some models only support 4 queues.
C13
spq Sets the Switch to use Strictly Priority Queuing (SPQ). C 13
wrr Sets the Switch to use Weighted Round Robin (WRR). C 13
