Chapter 73 Additional Commands
Ethernet Switch CLI Reference Guide
245
73.2 Command Examples
This example checks the cable pairs on port 7.
This example sends Ping requests to an Ethernet device with IP address 172.16.37.254.
traceroute help Provides more information about the specified command. E 0
write memory [<index>] Saves current configuration in volatile memory to the
configuration file the Switch is currently using or the specified
configuration file.
E13
Table 153 Command Summary: Additional Configure Mode
COMMAND DESCRIPTION M P
bcp-transparency Enables Bridge Control Protocol (BCP) transparency on the
Switch.
C13
default-management <in-
band|out-of-band>
Sets which traffic flow (in-band or out-of-band) the Switch
sends packets or originating from itself (such as SNMP traps,
ping
C13
hostname <name> Sets the Switch’s name for identification purposes.
name: 1-64 printable characters; spaces are allowed if you
put the string in double quotation marks (“).
C13
transceiver-ddm timer <1 -
4294967>
Sets the duration of the digital diagnostic monitoring (DDM)
timer.
This defines how often (in miliseconds) the Switch sends the
digital diagnostic monitoring (DDM) information via the
installed transceiver(s).
C13
Table 152 Command Summary: Additional Enable Mode (continued)
COMMAND DESCRIPTION M P
sysname# cable-diagnostics 7
port 7
cable diagnostics result
pairA: Ok
pairB: Ok
sysname# ping 172.16.37.254
Resolving 172.16.37.254... 172.16.37.254
sent rcvd rate rtt avg mdev max min reply from
1 1 100 0 0 0 0 0 172.16.37.254
2 2 100 0 0 0 0 0 172.16.37.254
3 3 100 10 1 3 10 0 172.16.37.254
