Zyxel MGS-3712F [110/284] Command examples
![Zyxel MGS-3712F [110/284] Command examples](/views2/1169509/page110/bg6e.png)
Chapter 25 Interface Commands
Ethernet Switch CLI Reference Guide
110
25.2 Command Examples
This example looks at the current status of port 1.
The following table describes the labels in this screen.
intrusion-lock Enables intrusion lock on the port(s) and a port cannot be
connected again after you disconnected the cable.
C13
no intrusion-lock Disables intrusion-lock on a port so that a port can be
connected again after you disconnected the cable.
C13
Table 68 interface Command Summary (continued)
COMMAND DESCRIPTION M P
sysname# show interfaces 1
Port Info Port NO. :1
Link :100M/F
Status :FORWARDING
LACP :Disabled
TxPkts :7214
RxPkts :395454
Errors :0
Tx KBs/s :0.0
Rx KBs/s :0.0
Up Time :127:26:26
TX Packet Tx Packets :7214
Multicast :0
Broadcast :163
Pause :0
RX Packet Rx Packets :395454
Multicast :186495
Broadcast :200177
Pause :0
TX Collison Single :0
Multiple :0
Excessive :0
Late :0
Error Packet RX CRC :0
Runt :0
Distribution 64 :285034
65 to 127 :31914
128 to 255 :22277
256 to 511 :50546
512 to 1023 :1420
1024 to 1518 :4268
Giant :0
Table 69 show interfaces
LABEL DESCRIPTION
Port Info
Port NO. This field displays the port number you are viewing.
