OKI ml5100fb [12/53] Producing a test print
![OKI ML5100FBeco [12/53] Producing a test print](/views2/1074038/page12/bgc.png)
Getting started > 12
P
RODUCING
A
TEST
PRINT
To check that your printer is operational, produce a test print on a sheet of 80 gsm A4 paper
(for example) as follows:
1. Turn the printer Power Switch to OFF.
2. Set the Paper Type Lever to cut sheet and set the Paper Thickness Lever to position
1.
3. Press and hold the LF/FF button and turn the Power Switch to ON. The alarm
indicator should be illuminated to indicate that there is no paper in the printer.
4. With the long side of the paper against the paper guide, insert the paper carefully
into the printer. The printer will automatically grip the paper and start the test print.
5. When the test print has completed, the paper is automatically ejected.
CAUTION!
> Allow at least 5 seconds between turning the printer ON after
turning it OFF. A shorter time interval between turning ON/OFF
operations may cause printer power failure.
> Do not turn the printer OFF while it is printing as this may result
in damage to the print head.
NOTE
If required, you can pause the test print by pressing the SEL button and then
resume the test print by again pressing the SEL button.
NOTE
If you want to abort the test print for any reason, press the SEL button
followed by the LOAD/PARK button to eject the paper and then turn the printer
Power Switch to OFF.
