Operating instructions > 30
Paper width mode Selects continuous form paper
width used. Select Mode1 when
using paper
≥8 inches wide,
Mode2 when using paper >5
but <8 inches wide, and Mode3
when using paper less than <5
inches wide.
Mode1
Mode2
Mode3
Continuous paper top LF
adjust Gap1
Selects top LF correction
amount for continuous form
paper, when paper thickness
level is 1 (Gap 1). The positive
range adds correction amounts
to the LF, and the negative
range reduces the correction
amounts to the LF. The amount
of LF is in 1/360 inch
increments.
-3 - -1
0
+3 - +1
Continuous paper top LF
adjust Gap2
Selects top LF correction
amount for continuous form
paper, when paper thickness
level is 2 (Gap 2). The positive
range adds correction amounts
to the LF, and the negative
range reduces the correction
amounts to the LF. The amount
of LF is in 1/360 inch
increments.
-3 - -1
0
+3 - +1
Continuous paper top LF
adjust Gap3
Selects top LF correction
amount for continuous form
paper, when paper thickness
level is 3 (Gap 3). The positive
range adds correction amounts
to the LF, and the negative
range reduces the correction
amounts to the LF. The amount
of LF is in 1/360 inch
increments.
-3 - -1
0
+3 - +1
Continuous paper top LF
adjust Gap4
Selects top LF correction
amount for continuous form
paper, when paper thickness
level is 4 (Gap 4). The positive
range adds correction amounts
to the LF, and the negative
range reduces the correction
amounts to the LF. The amount
of LF is in 1/360 inch
increments.
-3 - -1
0
+3 - +1
Line Spacing Select line feed pitch. 6 LPI
8 LPI
Form Tear-Off Select manual or auto as the
method to advance a
continuous form to the form
tear-off position.
Off
500 ms
1 sec
2 sec
Skip Over Perforation Select whether to skip over
perforation or not. (When a skip
over perforation setup
command is received, the
received command is given
priority.)
Yes
No
ITEM FUNCTION SETTING
