![OKI ML5100FBeco [33/53] Initialising menu settings](/views2/1074038/page33/bg21.png)
Operating instructions > 33
I
NITIALISING
MENU
SETTINGS
To restore the menu settings to their initial values, carry out the steps below.
1. Set the Power Switch to OFF.
2. Press and hold down the SEL and LOAD/PARK buttons together then set the Power
Switch to ON.
A
DJUSTING
TOF
POSITION
Use the following procedure to set TOF to accord with the reference position (6.35 mm
(0.25 in)). The reference position refers to the first line of the paper i.e. the position to
which the printer feeds the paper when automatically loading the paper.
1. Print out the menu settings of the printer as in “Confirming current settings” on
page 26 and confirm that the TOF (in cut sheet mode or continuous forms mode) is
6.35 mm (0.25 in).
2. Set the Paper Type lever to the required paper type.
3. When continuous forms are used, place the paper on the Pin Tractor.
For cut sheet mode, do not insert the paper at this stage.
4. In continuous forms mode, press the LOAD/PARK button.
In cut sheet manual feeding mode, press the LOAD/PARK button and place the paper
on the Paper Tray.
Registration Low Adjust the print starting
position on printing in the
reverse direction. (The position
moves to the right or left in 1/
720 in increments.)
-10 – -1
0
+10 – +1
Registration Normal Adjust the print starting
position on printing in the
reverse direction. (The position
moves to the right or left in 1/
720 in increments.)
-10 – -1
0
+10 – +1
Registration High1 Adjust the print starting
position on printing in the
reverse direction. (The position
moves to the right or left in 1/
720 in increments.)
-10 – -1
0
+10 – +1
Registration High2 Adjust the print starting
position on printing in the
reverse direction. (The position
moves to the right or left in 1/
720 in increments.)
-10 – -1
0
+10 – +1
LF Revise (Cut Sheet) Adjust a line feed amount in
cut-paper mode.
-14 – -1
0
+14 – +1
NOTE
The values adjusted by the Adjustment menus are not initialised by the
following procedure.
NOTE
Adjusting of TOF can be done in cut sheet mode or continuous forms mode.
ITEM FUNCTION SETTING
