Operating instructions > 31
Page Length
(Continuous)
Select the length of a
continuous form.
3.5 in, 4 in, 5.5 in, 6 in, 7 in,
8 in, 8.5 in, 11 in, 11 2/3 in,
12 in, 14 in, 17 in, 5 in, 3 in,
3.25 in
TOF (Continuous) Select the reference position for
the TOF position when auto
loading continuous form paper
from the rear of the printer. (Up
to the mid-section of characters
in the first line.)
2.12 mm (1/12 in)
4.23 mm (1/6 in)
6.35 mm (1/4 in)
8.47 mm (1/3 in)
10.58 mm (5/12 in)
12.7 mm (1/2 in)
14.82 mm (7/12 in)
16.93 mm (2/3 in)
19.05 mm (3/4 in)
21.17 mm (5/6 in)
23.28 mm (11/12 in)
25.4 mm (1 in)
27.52 mm (13/12 in)
1Chr. Set Pos.
Initial Position This is the position of the paper
when the paper is already
loaded at power on. (For
continuous form mode only.)
Print
Tear OFF
Auto Eject Position Select a printable area at the
bottom of cut sheets of paper in
cut-paper mode (the character
centre position).
6.35 mm (1/4 in)
14.8 mm
Page Length (Cut Sheet) Select the page length of cut-
paper.
3.5 in, 4 in, 5.5 in, 6 in, 7 in, 8
in, 8.5 in, 11 in, 11 2/3 in, 12
in, 14 in, 16.57 in, 5 in, 3 in,
3.25 in
TOF (Cut Sheet) Select the reference position for
the TOF position when feeding
cut-paper in manual mode. (Up
to the mid-section of characters
in the first line.)
2.12 mm (1/12 in)
4.23 mm (1/6 in)
6.35 mm (1/4 in)
8.47 mm (1/3 in)
10.58 mm (5/12 in)
12.7 mm (1/2 in)
14.82 mm (7/12 in)
16.93 mm (2/3 in)
19.05 mm (3/4 in)
21.17 mm (5/6 in)
23.28 mm (11/12 in)
25.4 mm (1 in)
27.52 mm (13/12 in)
1Chr. Set Pos.
Wait Time Select the waiting time between
setting paper on the tray and
feeding it while the printer is
waiting for paper to be fed in
cut-paper manual feed mode.
500 ms
1 sec
2 sec
FF Function
*EPSON only
Set feeding operation upon
receiving an FF code after cut-
paper is fed.
Eject
Form Feed
I-Prime Select whether to print or clear
buffer contents upon
initialisation by receiving I-
PRIME.
Invalid
Buffer Clear
Buffer Print
Auto Feed XT
*EPSON only
Set the validity of an Auto Feed
XT signal.
Valid
Invalid
ITEM FUNCTION SETTING
