OKI ml5100fb [27/53] Menu items and settings
![OKI ML5100FBeco [27/53] Menu items and settings](/views2/1074038/page27/bg1b.png)
Operating instructions > 27
M
ENU
ITEMS
AND
SETTINGS
In the menu settings tables below, factory default settings are shown emboldened.
ITEM FUNCTION SETTING
Emulation Mode Select EPSON LQ mode, IBM
PPR mode, or IBM X24 AGM
mode.
IBM PPR
IBM AGM
EPSON LQ
Print Mode Select quality of ANK
characters.
LQ Courier
LQ Roman
LQ Swiss
LQ Swiss Bold
LQ Orator
LQ Gothic
LQ Prestige
LQ OCR-A
LQ OCR-B
Utility
HSD
Pitch Select character pitch. 10 CPI, 12 CPI, 15 CPI, 17.1
CPI, 20 CPI
Proportional Spacing Select whether to use
proportional spacing or not.
Yes
No
Style Select either font style. Normal, Italics
Size Select the character scale size. Single, Double
Character Set Select either ANK character
code table.
Set I
Set II
Language Set Select a language character set. ASCII, French, German,
English, Danish I, Swedish I,
Italian, Spanish I, Japanese,
Norwegian, Danish II, Spanish
II, Latin American, French
Canadian, Dutch, Swedish II,
Swedish III, Swedish IV,
Turkish, Swiss I, Swiss II,
Publisher
Zero Character Select either print font pattern
to receive a zero character
located at 30H in ANK code.
Unslashed
Slashed
