Operating instructions > 26
S
ETTING
MENU
VALUES
The following information explains the printer settings and how you can change them.
Printer items and their values are printed for reference.
C
ONFIRMING
CURRENT
SETTINGS
To print the current menu settings, use a cut sheet of A4 paper or continuous forms of width
at least 254 mm. In this example, a sheet of A4 paper is used.
1. Set the Paper Type lever to cut sheet mode.
2. To activate menu mode:
(a) Ensure that the printer is powered OFF.
(b) While holding down the LOAD/PARK button set the printer Power Switch to ON.
3. Place the cut sheet on the Paper Tray.
4. Press the LF/FF button and the printer prints out all the menu items currently
selected and their corresponding settings.
5. Exit or proceed to change menu settings:
(a) To exit menu settings confirmation, save the current settings and eject the
paper, press and hold the LOAD/PARK button, then press the LF/FF and the SEL
buttons together.
(b) To change menu settings, see “Menu setting” on page 26.
M
ENU
SETTING
Set menu item values (printed out for reference as you proceed) as follows:
1. Press LOAD/PARK button and turn the Power ON, to enter the menu mode.
2. Place the cut sheet on the Paper Tray.
3. Press SEL to step forward, and hold LOAD/PARK and press SEL to step backward
through the menu items to the required item.
4. To change the setting for a selected item, press LF/FF to step forward, and press
LOAD/PARK + LF/FF to step backward through the setting values to the required
setting.
5. Repeat steps 3 and 4 as required to change settings for other items.
6. To exit menu setting, press and hold the LOAD/PARK button, then press SEL and LF/
FF together to save the new settings and exit menu setting mode.
NOTE
Before changing menu settings, you may wish to print the current menu
settings as in “Confirming current settings” on page 26.
NOTE
Switching the printer OFF does not save the new settings.
