![OKI ML5100FBeco [32/53] Item function setting](/views2/1074038/page32/bg20.png)
Operating instructions > 32
I/F Bi-Direction Set whether to return a device
ID or not in accordance with
IEEE1284.
Enable
Disable
Parity None: Absence of parity bit
Odd: Odd parity
Even: Even parity
Ignore: Do not convert the
character to ox40 in case of
parity error.
None
Odd
Even
Ignore
Serial Bits Select the data bit length. 7 Bits
8 Bits
Protocol Select an I/F Busy control
method.
Ready/Busy: Busy control by a
DTR signal
X-ON/X-OFF: Busy control by a
DC3/DC1 code
DTR X-ON/X-OFF: Busy control
DTR Signal and DC3/DC1
control.
Ready/Busy
X-On/X-OFF
DTR X-ON/X-OFF
Diagnostic Test Select to perform input/output
diagnosis of
RS-232C interface signals.
No
YES
Baud Rate Select to set the Baud rate. 300bps
600bps
1200bps
2400bps
4800bps
9600bps
19,200 bps
DTR Signal Set a method to switch a DTR
signal of a serial interface.
Ready on Power UP
Ready on Select
Busy Time Set the minimum time between
BUSY to READY.
0.2 sec
1 sec
TOF Adjustment
(Cut Sheet)
Select an adjustment value for
the reference position in regard
to the TOF position of cut-
paper/passbooks.
The position moves to the rear
of the form by [+] and to the
top of the form by [-] in 1/60 in
increments.
-7 – -1
0
+7 – +1
Rear Load Adjustment Select an adjustment value for
the reference position in regard
to the TOF position of a
continuous form.
The position moves to the rear
of the form by [+] and to the
top of the form by [-] in 1/60 in
increments.
-7 – -1
0
+7 – +1
Cut Position Adjust Select an adjustment value for
the position to cut the end of a
continuous form. (In 1/90 in
increments)
-7 – -1
0
+7 – +1
ITEM FUNCTION SETTING
