DG834G Reference Manual
Connecting the Router to the Internet 3-7
v3.0, September 2005
b. Connect the Ethernet cable (D) from a ADSL modem router LAN port to the Ethernet
adapter in your computer.
c. Connect the power adapter to the firewall and plug it in to a power outlet. Verify the
following:
The power light is lit after turning on the firewall.
The test light comes on briefly, then goes off.
The wireless light is lit after turning on the firewall.
The ADSL light is green, indicating you are connected to the ADSL network.
d. Now, turn on your computer. If software usually logs you in to your Internet connection,
do not run that software. Cancel it if it starts automatically. Verify the following:
The local lights are lit for any connected computers.
Figure 3-6
Phone
ADSL
Line
D
