DG834G Reference Manual
3-8 Connecting the Router to the Internet
v3.0, September 2005
3. Log in to the ADSL modem router.
a. Type http://Default IP Address Variable in the address field of a browser such as Internet
Explorer or Netscape
®
Navigator.
This login window opens:
Enter admin for the user name and password for the password, both in lower case letters.
Note: Your computer needs to be configured for DHCP. For instructions on
configuring for DHCP, please see the documentation that came with your
computer or “Preparing a Computer for Network Access”.
Figure 3-7
Figure 3-8
