Figure 5.26

 The number “x/x...” to the upper right corner of the screen

indicates the maximum frames that can be recorded and the

number of recorded frames.

6) The scan tool keeps recording PID data until user presses the

ESC button, selected memory location is full, or it completes

recording. A message prompting to playback data shows on the

screen.

Figure 5.27

 If you wish to playback recorded data, press the OK button; if

you do not wish to playback, press the ESC button, or use

LEFT/RIGHT button to select NO and press the OK button

to return to Record Data menu.

Recording Custom Data Set

1) To record customized data, use the UP/DOWN scroll button to

select Custom Data Set from Record Data menu and press the

OK button. (Figure 5.20)

Record Data

Recording Done!

Playback data?

YES NO

…….Recording…. 5/46 …..

DTC_CNT 0

FUELSYS1 0L

FUELSYS2 -- ?

LOAD_PCT(%) 0.0

ETC(℃) -40

SHRTFT1(%) 99.2
