D-Link DWC-2000 User Manual 111

Section 4 - Advanced WLAN Conguration

Field Description

Server Address

Enter the IP address of the host where the upgrade le is located. The host must have

a TFTP server installed and running.

File Path

Enter the le path on the TFTP server where the software is located. You may enter up

to 96 characters.

File Name

Enter the name of the upgrade le. You may enter up to 32 characters, and the le

extension .tar must be included.

Group Size

When you upgrade multiple APs, each AP contacts the TFTP server to download the

upgrade le. To prevent the TFTP server from being overloaded, you can limit the

number of APs to be upgraded at a time.

In the Group Size eld, enter the number of APs that can be upgraded at the same

time. When one group completes the upgrade, the next group begins the process.

Image Download Type

Type of the image to be downloaded, which can be one of the following:

• All Images

• DWL-8600AP

• DWL-3600AP/ DWL-6600AP

• DWL-2600AP

• DWL-8610AP

Note: To download all images, make sure you specify the le path and le name for

both images in the appropriate File Path and File Name elds.

Managed AP

The list shows all the APs that the controller manages. If the controller is the Cluster

Controller, then the list shows the APs managed by all controllers in the cluster.

Each AP is identied by its MAC address, IP address, and Location in the <MAC ‐ IP ‐

Location> format. To upgrade a single AP, select the AP MAC address from the drop

down list. To upgrade all APs, select All from the top of the list. If All is selected, the

Group Size eld will limit the number of simultaneous AP upgrades in order not to

overwhelm the TFTP server. To select multiple APs to upgrade, CTRL + click the APs

to upgrade.

Note: D‐Link recommends that you upgrade all managed APs at the same time.
