D-Link DWC-2000 User Manual 220
Section 7 - Viewing Status and Statistics
Field Description
BSSID
Shows the BSSID of the AP against which the attack is launched. The BSSID is a
MAC address.
Channel Identies the channel on which the rogue AP is operating.
Time Since Attack Started Shows the amount of time that has passed since the attack started on the AP.
RF Scan Report Age Shows the amount of time that has passed since the RF Scan reported this AP.
