D-Link DWC-2000 [267/282] Tracking traffic routing logs
![D-Link DWC-2000 [267/282] Tracking traffic routing logs](/views2/1203427/page267/bg10b.png)
D-Link DWC-2000 User Manual 267
Section 10 - Troubleshooting
Option Description
Accepted Packets If enabled, tracks packets that were transferred through the segment successfully.
Dropped Packets
If enabled, tracks packets that were blocked from being transferred through the
segment.
Routing Logs
Inter VLAN: If enable, tracks trac from inter VLAN routing logs.
Tracking Trac/Routing Logs
Maintenance > Logs Settings > Routing Logs
Trac can be tracked based on whether the packet was accepted or dropped by the rewall. Denial of service
attacks, general attack information, login attempts, dropped packets, and similar events can be captured for
review by the IT administrator.
Note: Enabling logging options may generate a signicant volume of log messages and is recommended for
debugging purposes only.
After making your selections on this page, click Save to save your changes or click Cancel to revert to the previous
settings.
