Section 5 - Advanced Network Conguration

Double VLANs

Path: Network > VLAN > Advanced VLAN > Double VLAN

Double VLAN Tunneling allows the use of a second tag on network trac. The additional tag helps dierentiate

between customers in the Metropolitan Area Networks (MAN) while preserving individual customer’s VLAN

identication when they enter their own 802.1Q domain.

With the introduction of this second tag, you do not need to divide the 4k VLAN ID space to send trac on an

Ethernet‐based MAN.

With Double VLAN Tunneling enabled, every frame that is transmitted from an interface has a DVlan Tag attached

while every packet that is received from an interface has a tag removed (if one or more tags are present).

Use the Double VLAN Tunneling page to congure Double VLAN frame tagging on one or more ports.

1. Go to Network > VLAN > Advanced VLAN > Double VLAN tab.

2. Click Add New Double VLAN.

3. Select the Ether Type: Dot1q, VLAN, or Custom Tag.

4. Click Save.

3. Complete the elds in the table below and click Save.

Field Description

VLAN ID Specify the VLAN ID to associate with this group. The range is 1‐3965.

Group ID Identies the group to congure.

Group Name

(Optional) Enter or modify a name to associate with protocol group ID. The name can

be up to 16 characters.

Interface Selects the interface(s) to add or remove from this group.

Protocol List Specify one or more protocols to associate with this group.
