D-Link DWC-2000 User Manual 214

Section 7 - Viewing Status and Statistics

Field Description

Model Name The model of the managed AP.

Firmware Version The rmware version of the managed AP.

MAC Address (*) Peer Managed

Ethernet address of the managed access point. If an asterisk (*) follows the

MAC address, the access point is managed by a peer controller.

IP Address Network IP address of the managed access point.

Location

An optional description of where the AP is physically located. Congured

through the AP management section.

Status

Current managed state of the access point. Possible values are:

• Discovered = access point is discovered by the wireless controller, but not

authenticated.

• Authenticated = access point has been validated and authenticated (if

authentication is enabled), but it is not congured.

• Managed = prole conguration has been applied to the access point

and the access point is operating in managed mode.

• Failed = wireless controller lost contact with the access point. A failed

entry remains in the Managed AP database, unless you remove it. Note

that a managed access point shows a failed status temporarily during a

reset.

If management connectivity is lost for a managed access point, both of

its radios are turned down and all clients associated with the access point

are disassociated. The radios resume operation when that access point is

managed again by a wireless controller.

Conguration Status

Shows whether the conguration prole applied to the managed access point

is successful or not.

Managed

Path: Status > Wireless Information > Access Point > Managed

The Managed AP List page shows details about the managed access point. right clicking a managed access point

enables more options.
