D-Link DWC-2000 User Manual 170
Section 6 - Securing Your Network
Conguring Browser Policies
Path: Security > Authentication > User Database > Groups
The following procedure describes how to congure browser-specic policies for user groups. Using this
procedure, you can allow or deny the users in a user group from using particular web browsers to log in to the
wireless controllers’ web management interface.
1. Click Security > Authentication > User Database > Groups.
2. Click the Add Browser Policies button.
3. Under Add Dened Browser, click a browser from the Client Browser drop-down list and click Add. The
selected browser will appear in the Dened Browsers area.
Field Description
Group Name Select the group name from the drop-down menu.
Client Browser Select a web browser from the drop-down menu.
