D-Link DWC-2000 User Manual 155

Section 5 - Advanced Network Conguration

Field Description

Prole Name The name of the prole.

Port Select a port or ports. Hold CTRL to select multiple ports.

Prole Type

Matching criteria of this prole. The criteria are:

• VLAN

• Destination MAC Address

• Source MAC Address

• Destination IP Address

• Source IP Address

• Source TCP Port

• Destination TCP Port

• Source UDP Address

• Destination UDP Address

VLAN If Prole Type = VLAN, enter a dened VLAN number.

MAC Address

If Prole Type = Destination MAC Address or Source MAC Address, enter a dened

MAC Address.

IP Address

If Prole Type = Destination IP Address or Source IP Address, enter a dened IP

Address.

L4 Port

If Prole Type= Source TCP Port, Destination TCP Port, Source UDP Port or Destination

UDP Address, enter a dened port number.

Priority

Priority of the QoS rule. The priority choices are:

• Highest

• High

• Low

• Lowest
