D-Link Unified Access System Software User Manual

02/15/2011

Page 138 Document 34CS3000-SWUM104-D10

To view additional data (beacon information) for an AP in the failure list, you can search for the MAC address of the failed

AP on the Rogue/RF Scan page. However, some APs that attempt to contact the switch on the wired network might not be

detected during the RF scan.

• Click Back to see a list of Authentication Failed Access Points.

• Click Refresh to update the screen with the most current information.

Monitoring Rogue and RF Scan Access Points

The radios on each D-Link Access Point can periodically scan the radio frequency to collect information about other APs and

wireless clients that are within range. In normal operating mode the AP always scans on the operational channel for the

radio. Two other scan modes are available for each radio on the APs:

• Scan Other Channels—Configures the AP to periodically leave its operational channel and scan other channels within

that frequency.

• Scan Sentry—Disables normal operation of the radio and performs a continuous radio scan. In this mode, no beacons

are sent, and no clients are allowed to associate with the AP.

When Scan Other Channels or Scan Sentry modes are enabled, the AP scans all available channels on each radio. When

the scan is complete, the AP sends information it collected during the RF scan to the switch that manages it. For information

about how to configure the scan mode, see “Configuring Wireless Radio Settings” on page 81.

The D-Link Unified Switch considers an access point to be a Rogue if is detected during the RF scan process and the MAC

address of the detected AP is not in the local or RADIUS Valid AP database or if the AP is not managed by a peer switch.

To start mitigation on any Rogue Access Point, select the checkbox of the AP and click Add to Attack List.

From the Monitoring > Access Points > Rogue/RF Scan Access Points page, you can view information about all APs

detected via RF scan, including those reported as Rogues.

You can sort the APs in the list based any of the column headings. For example, to group all Rogue APs together, click

Status.

Table 42: Access Point Authentication Failure Status

Field Description

MAC Address The Ethernet address of the AP.

IP Address The network IP address of the AP.

Last Failure Type Indicates the last type of failure that occurred.

Vendor ID Vendor of the AP software.

Validation Failures The count of association failures for this AP.

Authentication Failures The count of authentication failures for this AP.

Protocol Version Indicates the protocol version supported by the software on the AP.

Software Version Indicates the version of software on the AP.

Hardware Type Hardware platform for the AP.

Age Time in seconds since failure occurred.
