Software User Manual D-Link Unified Access System

02/15/2011

Document 34CS3000-SWUM104-D10 Page 181

Table 72 describes the fields on the Interface Association page.

Use the following steps to associate one or more interfaces with a captive portal.

1 Select the desired captive portal from the CP Configuration list.

2 Select the interface or interfaces from the Interface List. To select more than one interface, hold the Ctrl key and click

multiple interfaces.

3 Click Add.

Use the following steps to remove an interface from the Associated Interfaces list for a captive portal.

1 Select the desired captive portal from the CP Configuration list.

2 In the Associated Interfaces field, select the interface or interfaces to remove. To select more than one interface, hold

the Ctrl key and click multiple interfaces.

3 Click Delete.

The interface is removed from the Associated Interface list and appears in the Interface List.

Click Refresh to update the screen with the most current information.

Viewing the Captive Portal Global Status

The CP Global Status page contains a variety of information about the CP feature. From the CP Global Status page, you

can access information about the CP activity and interfaces.

To view captive portal status information, click Security > Captive Portal > CP Status.

Table 72: Global Captive Portal Configuration

Field Description

CP Configuration Lists the captive portals configured on the switch by number and name.

Associated Interfaces Lists the interfaces that are currently associated with the selected captive portal. Wireless

interfaces are identified by the wireless network number and SSID. Physical (wired) interfaces

are identified by the Port Description that includes slot number, port number, and interface

type.

Interface List Lists the interfaces available on the switch that are not currently associated with a CP.

Wireless interfaces are identified by the wireless network number and SSID. Physical (wired)

interfaces are identified by the Port Description that includes slot number, port number, and

interface type. The range is an integer.

Note: When you associate an interface with a captive portal, the interface is removed from the Interface List. Each

interface can be associated with only one CP at a time.
